180m Depth XY-1A Core Drilling Rig Water Well Drilling Rig Machine For Engineering Investigation
Introduction of Core drilling rig
Oil pressure feeding system to improve drilling efficiency and lighten labor strength. It configures upper ball clip clamping mechanism together with 6 sides' active drilling rod to practice pole collapse when running, high efficiency, safe and reliable.Centralized handles and convenient operation.Compact structure, small volume, light weight, strong resolvability and easy to move, which is suitable to work in plain or mountain area.
Core drilling rig parameters
| XY-1A Type |
| Drill | Swivel Head |
| Drilling depth | Max.150m | Spindle speed | 1010,790,470,295,140(r/min) |
| Hole diameter | Max.150m | Spindle stroke | 450kmm |
| Drill rod diameter | 42.50mm | Spindle pull-down | Max.15KN |
| Angle range | 90-75 | Spindle lifting capacity | Max. 25KN |
| Oil pump | Water pump |
| Model | YBC-12/125 | Model | Horizontal reciprocating single-acting piston pump |
| Rated pressure | 12.5Mpa | Working pressure | Max. 1.25Mpa |
| Flow speed | 8ml/r | | |
| Rated speed | 1500r/min | | |
| Hoist | Power(diesel) |
| Max. lifting capacity | 15KN | Model(diesel engine) | 1105 |
| Hoisting drum revolution | 121,76,36(r/min) | Rated power | 18KW |
| Drum diameter | 140mm | Rated speed | 2200r/m |
| WEIGHT | AROUND 600KG |
| SIZE | 1620*970*1560mm |
The main features of core drill rig are as follows
Drilling and various concrete structure peep hole in solid ore bed survey and engineering geological prospecting.According to different geological conditions, you can choose drilling bit kinds: diamond, alloy and steel particles to drill.When hole termination are 75mm and 46mm separately, the rating drilling depth is 100m and 180m. The max. depth can not exceed 110% of each drilling, the maximum boring diameter can be 150mm.
FAQ
1. Q: Are you a factory or a trading company? A: We are trading companies and manufacturers. Extensive experience in machinery and equipment.
2. Q: How long is your delivery time?
A: It is according to the model and quantity. Generally it is 3-5 days if the machines are in stock. It will be 15-30 days if you
want to customize the machines.
3. Q: What are your payment terms?
A: We accept L/C, T/T and Western union is available. etc.
4. Q:Besides machines,can you provide tools of machines?
A:Yes.Both machines and tools can be provided in our factory.Our company has an independent spare-part departments.If you just only need tools of your machines,we can also provide you even if your machine is originally not from our factory. Just tell us your needs and we can make a free design for you.
5.Q: Is it possible to manufacture products according to the drawings provided by customers?
A: Yes, we can provide customized services, you can provide us with ideas or drawings, and we will do our best to meet
your requirements.
